MTRJ CONNECTOR
Description
CommuniChina can supply a wide range of fiber optic connectors for various applications.
High quality MTRJ series connectors are one of the popular types among our customers.
Features:
* Single-mode, Duplex
* ANSI \ IEC \ TIA/EIA \ NTT and JIS standard compatible
* 2.0mm or 3.0mm cable available
* Multi-piece type or one-piece type is available
* Available in customied colours and customied packaging
* Precision mechanical dimensions
* Low insertion loss and back reflection
* UPC or 8 degree APC are available
* Complies with IEC 61754-4,IEC 60784-14 and Tia 604-3
* Content RoHS claim
Application:
* FTTP
* CATV; LAN & WAN
* Network; Broadband
* Telecommunication
Specification:
|
Type |
MTRJ duplex connector |
|
Mode |
Single-mode |
|
Insertion Loss |
≤0.2dB |
|
Durability (1000 Mating) |
≤0.2dB |
|
Operating Temperature |
-40~+80 centigrade degree |
|
Storage Temperature |
-40~+85 centigrade degree |
