LC-MM-DX Patch Cord
Description:
CommuniChina can supply you a wide range of terminating fiber optic products for various applications. The featured products are manufactured using high quality components and the most sophisticated mechanical polishing techniques. Communichina’s patch cords are available in any a variety of connection configurations including standard and small form factor connectors that is SC, LC, FC, ST, MTRJ, MU, MPO, and E2000; PC, UPC, APC 8 degree for single mode patch cord, and SC, LC, FC, ST, MTRJ and MPO for the multi mode patch cord.
Features:
* Telcordia GR-326-CORE Compliant
* RoHs, LSZH compliant
* IEC standard compatible
* Low insertion loss and back reflection
* High consistent quality and short lead time
* Standard/small form factor connector styles
* Available in customized colors and package
* Precision pre-grinding Zirconia Ceramic Ferrules
Application:
* FTTP
* CATV
* LAN & WAN
* Network
* Broadband
* Telecommunication
Specification:
|
Item |
Mode Type |
PC |
UPC |
APC |
|
Insertion Loss |
SM |
≤ 0.25dB |
≤ 0.20dB |
≤ 0.20dB |
|
MM |
≤ 0.30dB |
≤ 0.20dB |
---- |
|
|
Return Loss |
SM |
≥ 50dB |
≥ 55dB |
≥ 65dB |
|
MM |
≥ 35dB |
≥ 35dB |
---- |
|
|
Durability |
1000 times |
|||
|
Repetition Test |
Additional Loss≤ 0.1dB, Return Loss Variability 5dB |
|||
|
Temperature Stability (-40~85℃) |
Additional Loss≤ 0.2dB, Return Loss Variability 5dB |
|||
|
Operating Temperature |
-40~+80 ℃ |
|||
|
Storage Temperature |
-40~+85 ℃ |
|||
|
Fiber Type |
SM G652.D; G657.A,B; OM1, OM2,OM3,OM4…… |
|||
|
Cable Diameter |
0.9mm, 2.0mm, 3.0mm …… |
|||
|
Material |
PVC/LSZH Jacket, Hytrel aramid yarn, Zirconia Ceramic Ferrule, Corning fiber |
|||
